The interference coverage is comprehensive.

Directional suppression and FPV image transmission interference cover the entire frequency band from 300 MHz to 6 GHz.

Eight key frequency points are preset, and up to six additional frequency bands can be suppressed simultaneously.

There are no blind spots in the search.

The scanning mode has an azimuth range of 0° to 360° and an elevation range of 0° to 30° (with a selectable 60°).

The sweeping mode has an azimuth range of -45° to 45° and an elevation range of 0° to 30° (with a selectable 60°).

It provides comprehensive coverage of the monitored area.

The detection range is long.

The radar can detect targets with RCS of 0.01 m² over a distance of more than 5 km, and targets with RCS of 0.05 m² over a distance of more than 7.5 km.

The electro-optical tracking is ideal for DJI drones in the environment and can cover a wide area.

The tracking is precise and efficient.

It supports dual-mode tracking and can simultaneously track up to 4 targets.

The search and tracking accuracy both reach a distance of less than 10 meters and an azimuth/elevation of less than 0.6°.

The turret tracking accuracy is ≤ 1 mrad.
